Belt Transmission Blade Table Co2 Laser Engraving Machine For Double-color Board Engraving
This type co2 laser engraving machine is made for double-color board engraving, it could add one or three more laser heads.
| Model | DHCL-1390 |
| Table Type | Blade table |
| Laser Power | 90W-100W RECI laser tube |
| Working Area | 1300mm * 900mm |
| Control System | Leetro Control system |
| Lens and Mirrors | Singapore Wavelength lens and mirrors |
| Rails | PMI square rail |
| Transmission | Belt transmission |
| Motor and Driver | Leadshine stepper motor and driver |
| Cooling System | Water chiller CW 3000 |
| Others | USB offline, Red point, Industrial, Air pump ACO-009 etc |
Features
1. The blade table is suitable for hard materials engraving, it could bear high weight materials, made by stainless steel table;
2. Red Point
The red spot positioning lamp adopts imported laser diode and optical lens. Clear spot, low divergence, good collimation, small size, strong industrial applicability;
3. Leadshine stepper motor and driver, the CM series is a high-performance, lower-cost stepper motor made by Raytheon Smart with the latest Japanese design, the latest technology and imported core materials;
4. Reci laser tube, has good engraving performance, can use 4mA current in the high-frequency pulse engraving of the laser tube in pre-ionization state;
5. Inner part with optimized heat dissipation effect, rationalized placement of the electronic parts, Ensured system stability and anti jamming capability;
6. Leetro control system
Leetro control system adopts true color screen, support customer custom boot screen, support panel display processing graphics; Support CCD vision automatic edge finding cutting function;
7. Non-metal laser head, More in line with the latest design of mechanical engineering, greatly improve the laser conversion rate, fast carving speed, safe and durable, easy to operate;
8. Cooling machine adopted Industrial water chiller CW-3000, install easier and could make sure better cooling system to extended working hours;
9. Singapore imported lens and mirrors anti-reflection film, high-quality processing technology, high transmittance, stable performance;
10. Welded machine body
adopts thermal quenching technology to remove stress and uses a large precision gantry milling machine to ensure accuracy.
